Page 10

Photo - Pause for a photo - Canning Stock Route - Outback Western Australia
Using your compressor.
The remote control makes using your compressor very quick and convenient.
Regardless of which method of installation that you adopt, the method of use is the same.
After connecting the electrical cables to the compressor simply walk to the tire that you wish to inflate, remove the dust cap and attach the ball foot chuck to the valve.
Be sure that you have pressed the chuck right down onto the valve as it must be right down for the centre probe to depress the spring loaded valve and open it to allow air to flow into the tire.
Start the compressor by pressing the grey button or button number 1 in the newer units. If the compressor starts to labour or the pressure relief valve cycles you can be sure that the chuck is not properly connected to the valve. Correct this situation and try again.
The joy of using this system is that once you have connected the chuck you can perform the rest of the operation in a standing or sitting position if required.
Your back and your knees will love you for it!
After pumping for say 20 seconds press the orange button or the Number 1 button again on the remote to stop the compressor. Check the inline gauge to see what the pressure is then keep adding air in say 5 or 10 second increments until the desired pressure is achieved.
